Refine and correct this 3D timber roof structure to make it structurally realistic and logically organized. Main corrections Simplify the structure into a clear hierarchy Reduce the number of primary ribs to 3–4 main structural arches Define one main central structural spine and a few secondary branches Structural logic Align all branching columns directly under main load-bearing ribs Every column must clearly support a primary or secondary beam Remove any elements that do not clearly transfer loads Diagonal arch Rework the large diagonal arch: either connect it clearly to a column and make it a main load-bearing element or simplify/remove it if it has no structural logic Secondary structure Keep a lighter secondary grid between main ribs Reduce density of the grid toward the edges Make the structure denser and stronger above the main building Make it lighter and more open toward the outer canopy Gradation Create clear structural gradation: strongest and tallest elements above the main hall lighter structure toward the edges and over the outdoor market Columns Use fewer but stronger branching timber columns Place them mainly along the perimeter Keep interior space open Geometry Keep the original flowing roof shape Maintain the overall footprint and direction toward the river Do not redesign the form, only improve structure Output style architectural 3D structural model clean white background light wood material no people no textures no labels focus on structural clarity Important the result must look buildable and realistic not a freeform sculpture clearly readable load paths and hierarchy, keep exact camera angle
PromptRefine and correct this 3D timber roof structure to make it structurally realistic and logically organized. Main corrections Simplify the structure into a clear hierarchy Reduce the number of primary ribs to 3–4 main structural arches Define one main central structural spine and a few secondary branches Structural logic Align all branching columns directly under main load-bearing ribs Every column must clearly support a primary or secondary beam Remove any elements that do not clearly transfer loads Diagonal arch Rework the large diagonal arch: either connect it clearly to a column and make it a main load-bearing element or simplify/remove it if it has no structural logic Secondary structure Keep a lighter secondary grid between main ribs Reduce density of the grid toward the edges Make the structure denser and stronger above the main building Make it lighter and more open toward the outer canopy Gradation Create clear structural gradation: strongest and tallest elements above the main hall lighter structure toward the edges and over the outdoor market Columns Use fewer but stronger branching timber columns Place them mainly along the perimeter Keep interior space open Geometry Keep the original flowing roof shape Maintain the overall footprint and direction toward the river Do not redesign the form, only improve structure Output style architectural 3D structural model clean white background light wood material no people no textures no labels focus on structural clarity Important the result must look buildable and realistic not a freeform sculpture clearly readable load paths and hierarchy, keep exact camera angle
Date29 March 2026
