MAKE THE PAPER WHITE Enhance this architectural wall section sheet while keeping the EXACT layout, drawing positions, and composition unchanged. DO NOT move, resize, or redesign any drawings on the sheet. Only refine linework, add material layers, thickness, and detailed annotations. -------------------------------------------------- WALL ASSEMBLY OUTSIDE TO INSIDE — MUST BE CLEARLY DRAWN WITH THICKNESS: - Terracotta rainscreen panel ~1.25" thick, outermost layer - Ventilated air cavity 1.5"–2" gap, left empty - Aluminum rail / subframing system thin vertical supports - Continuous rigid insulation 2"–4", light hatch - Weather-resistive barrier thin line - Metal stud wall 6", with batt insulation hatch - Interior gypsum board 5/8", thin layer Ensure each layer is graphically distinct and readable. -------------------------------------------------- STRUCTURAL INTEGRATION: - Show concrete slab thickness 8"–10" - Show slab edge condition connecting to wall - Add drop panel if near column - Columns if visible should be darker poche -------------------------------------------------- FOUNDATION / GROUND CONDITION: - Show slab on grade condition - Add compacted base below slab - Indicate foundation or footing below - Add insulation at slab edge if visible -------------------------------------------------- WINDOW DETAIL VERY IMPORTANT: - Add recessed aluminum window frame within wall assembly - Show insulated glazing unit double line - Indicate head and sill condition - Show how window sits within insulation layer -------------------------------------------------- SHADING SYSTEM: - Add terracotta vertical shading fins offset from facade ~1'–2" - Include thin steel or aluminum support bracket - Keep aligned with facade system -------------------------------------------------- GRAPHIC STYLE: - Strong poche for cut elements slab, wall, column - Thin lines for background elements - Clean architectural detail drawing black + white - Minimal gray hatching for materials - No color rendering -------------------------------------------------- ANNOTATION CLEAN + PROFESSIONAL: Add labels with leader lines: - Terracotta Rainscreen Panel - Ventilated Air Cavity - Aluminum Subframe - Continuous Insulation - Weather Barrier - Metal Stud Wall 6" - Interior Gypsum Board - Concrete Slab - Slab Edge Condition - Slab on Grade - Aluminum Window Frame - Insulated Glazing Unit - Terracotta Shading Fins -------------------------------------------------- IMPORTANT: - DO NOT simplify the wall - DO NOT leave layers ambiguous - DO NOT over-render - Keep clarity and hierarchy - Make it read like a real construction detail, keep exact camera angle
PromptMAKE THE PAPER WHITE Enhance this architectural wall section sheet while keeping the EXACT layout, drawing positions, and composition unchanged. DO NOT move, resize, or redesign any drawings on the sheet. Only refine linework, add material layers, thickness, and detailed annotations. -------------------------------------------------- WALL ASSEMBLY (OUTSIDE TO INSIDE — MUST BE CLEARLY DRAWN WITH THICKNESS): - Terracotta rainscreen panel (~1.25" thick, outermost layer) - Ventilated air cavity (1.5"–2" gap, left empty) - Aluminum rail / subframing system (thin vertical supports) - Continuous rigid insulation (2"–4", light hatch) - Weather-resistive barrier (thin line) - Metal stud wall (6", with batt insulation hatch) - Interior gypsum board (5/8", thin layer) Ensure each layer is graphically distinct and readable. -------------------------------------------------- STRUCTURAL INTEGRATION: - Show concrete slab thickness (8"–10") - Show slab edge condition connecting to wall - Add drop panel if near column - Columns (if visible) should be darker poche -------------------------------------------------- FOUNDATION / GROUND CONDITION: - Show slab on grade condition - Add compacted base below slab - Indicate foundation or footing below - Add insulation at slab edge if visible -------------------------------------------------- WINDOW DETAIL (VERY IMPORTANT): - Add recessed aluminum window frame within wall assembly - Show insulated glazing unit (double line) - Indicate head and sill condition - Show how window sits within insulation layer -------------------------------------------------- SHADING SYSTEM: - Add terracotta vertical shading fins offset from facade (~1'–2") - Include thin steel or aluminum support bracket - Keep aligned with facade system -------------------------------------------------- GRAPHIC STYLE: - Strong poche for cut elements (slab, wall, column) - Thin lines for background elements - Clean architectural detail drawing (black + white) - Minimal gray hatching for materials - No color rendering -------------------------------------------------- ANNOTATION (CLEAN + PROFESSIONAL): Add labels with leader lines: - Terracotta Rainscreen Panel - Ventilated Air Cavity - Aluminum Subframe - Continuous Insulation - Weather Barrier - Metal Stud Wall (6") - Interior Gypsum Board - Concrete Slab - Slab Edge Condition - Slab on Grade - Aluminum Window Frame - Insulated Glazing Unit - Terracotta Shading Fins -------------------------------------------------- IMPORTANT: - DO NOT simplify the wall - DO NOT leave layers ambiguous - DO NOT over-render - Keep clarity and hierarchy - Make it read like a real construction detail, keep exact camera angle
Date29 April 2026
