Create a 3D structural model of an organic roof based exactly on the provided plan drawing.

Geometry IMPORTANT
The roof must strictly follow the footprint and shape of the uploaded plan
Do not simplify the geometry
Preserve all curves, asymmetry and flow lines from the plan
The roof extends beyond the main building as a continuous canopy following the same footprint
Dimensions
approximate footprint: 50 × 40 meters
height above main building: ~10 meters
roof gradually lowers towards the edges and exterior spaces
Structure
primary structure: curved glulam timber ribs
ribs must follow the main directional flow of the roof like water stream from the plan
spacing between ribs: 4–6 meters
secondary structure:
perpendicular timber beams forming a regular grid
Columns
support the roof with large branching timber columns tree-like / Y-shaped
place columns mainly:
along the edges of the roof
at key structural points from the plan
keep the interior of the market mostly column-free
Form logic
highest point located above the main historic building
roof surface flows and slopes down towards the river side
edges extend outward forming a protective canopy over exterior market areas
Expression
structure must be clearly readable
emphasize:
rhythm of ribs
direction of flow
structural logic
Style
conceptual architectural 3D model
clean white background
light wood material glulam
no textures, no people
focus on structure only
Important
strictly follow the provided plan geometry
do not invent a new shape
do not simplify curves
keep it architectural and realistic, keep exact camera angle

PromptCreate a 3D structural model of an organic roof based exactly on the provided plan drawing.

Geometry (IMPORTANT)
The roof must strictly follow the footprint and shape of the uploaded plan
Do not simplify the geometry
Preserve all curves, asymmetry and flow lines from the plan
The roof extends beyond the main building as a continuous canopy following the same footprint
Dimensions
approximate footprint: 50 × 40 meters
height above main building: ~10 meters
roof gradually lowers towards the edges and exterior spaces
Structure
primary structure: curved glulam timber ribs
ribs must follow the main directional flow of the roof (like water stream from the plan)
spacing between ribs: 4–6 meters
secondary structure:
perpendicular timber beams forming a regular grid
Columns
support the roof with large branching timber columns (tree-like / Y-shaped)
place columns mainly:
along the edges of the roof
at key structural points from the plan
keep the interior of the market mostly column-free
Form logic
highest point located above the main historic building
roof surface flows and slopes down towards the river side
edges extend outward forming a protective canopy over exterior market areas
Expression
structure must be clearly readable
emphasize:
rhythm of ribs
direction of flow
structural logic
Style
conceptual architectural 3D model
clean white background
light wood material (glulam)
no textures, no people
focus on structure only
Important
strictly follow the provided plan geometry
do not invent a new shape
do not simplify curves
keep it architectural and realistic, keep exact camera angle

Date29 March 2026
