Prompt: A professional, highly accurate 2D architectural technical floor plan of the second floor of a modern luxury single-family home, presented as a crisp digital blueprint vector illustration on a clean white background. Layout & Geometry: The plan is strictly symmetrical along a central vertical axis. At the bottom center, a grand semicircular curved staircase leads up into a central entry corridor labeled with elevation markings (+6. 80). The lower-left quadrant features a large open-to-below architectural void over a ground-floor pergola and driveway. The lower-right quadrant contains a rectangular bedroom measuring 340x360 cm with an attached private en-suite bathroom. Upper Wings & Balcony: The upper section of the layout splits into two mirrored, symmetrical bedroom wings oriented at sharp 45-degree angles. Each wing contains a spacious bedroom area and a dedicated private en-suite bathroom with standard symbols for a toilet, sink, and shower. Both 45-degree angled bedrooms open directly onto a massive, sweeping semicircular curved balcony that spans across the entire top perimeter of the floor plan. Technical Details & Style: Clean, precise black line work with professional architectural drafting symbols, hatch patterns for structural concrete columns, dual-line insulated walls, door swing indicators, and precise extension lines with dimension text labels in centimeters. High contrast, sharp technical resolution, blueprint CAD software style, zero perspective distortion, top-down orthographic blueprint projection
