I need to draw a layout of Facility with plot size (24.9 * 70 feet the 24.9 feet side is connected to road of 22 feet wide) which will handle DCU foundation size ( 3.25 * 2 meters ) connected to outlet of Cascade of 4500 WL ( size of foundation 6 * 2.5 meters ) the inlet of cascade is connected to Fillpost through SS tubing with trench size 300mm the fillpost is connected with mobile LCV requiring area ( 8 meter * 3 meter ) ensure safety guard between fill post and LCV , fencing should be there and it should be 2 meters from DCU . Kindly study all the guidelines ( T4s , OISD )and prepare a layout. show interdistances

Prompt: I need to draw a layout of Facility with plot size (24.9 * 70 feet the 24.9 feet side is connected to road of 22 feet wide) which will handle DCU foundation size ( 3.25 * 2 meters ) connected to outlet of Cascade of 4500 WL ( size of foundation 6 * 2.5 meters ) the inlet of cascade is connected to Fillpost through SS tubing with trench size 300mm the fillpost is connected with mobile LCV requiring area ( 8 meter * 3 meter ) ensure safety guard between fill post and LCV , fencing should be there and it should be 2 meters from DCU . Kindly study all the guidelines ( T4s , OISD )and prepare a layout. show interdistances
