A conceptual hand-drawn architectural masterplan diagram and urban design study for a triangular site. Urban Concept (Geometrical Tension & Dynamic Meander):Pivoted & Angled Masses: Instead of rigid parallel blocks, 3 distinct residential volumes (3 to 4 storeys) are strategically angled and rotated relative to the site boundaries. Spatial Tension & Funneling: The gaps between the building masses create dynamic spatial funnels—narrowing into intimate urban pedestrian passages and widening into generous sunlit pockets. East Urban Setback & Corner Accent: The building at the main road junction forms a solid 4-storey corner landmark, then recedes away from the road to create a widened public plaza with tree avenues, cafes, and outdoor seating. Scale Step-Down (West Edge): The angled buildings gradually step down from 4 storeys near the avenue to 3 storeys near the low-rise single-family homes, creating a respectful neighborhood transition. Flowing Meandering Landscape: A continuous green pedestrian park meanders dynamically through the angled spaces between the buildings on natural unbuilt ground. Graphic Style:Minimalist CAD site plan base with vibrant hand-drawn felt-tip marker overlays. Red angled blocks for building volumes with storey counts, blue dynamic arrows indicating spatial tension and wind/pedestrian movement through the narrowing gaps, and a organic green marker wash for the meandering park landscape. High-end architectural competition conceptual diagram.
