A 3D architectural cutaway diagram of a house and its entire underground wastewater system, showing a clear sequential flow. The system starts with two distinct clar grey PVC pipes coming from the house: one from the bathroom and one from the kitchen. The kitchen pipe leads into a dedicated underground green grease trap. Sequentially, the pipeline from the green grease trap slopes downward and connects into sewer Inspection Chamber Number 1 which diameter is 0,8 , where it meets the bathroom pipe. From this chamber Number 1, a single continuous clear grey PVC pipe runs downward into a yellow polyethylene septic tank. After the septic tank, the pipe connects to a sewer inspection chamber from infiltration dranages distribution that splits the flow into two black perforated drain pipes whose heading opposite directions, inside two infiltration trenches, whose are at the bottom of them, are filled with detailed layers of gravel and coarse sand. Clean visual layout, highly aesthetic, natural dirt trench texture with realistic green grass on top, clear technical visualization.

Prompt: A 3D architectural cutaway diagram of a house and its entire underground wastewater system, showing a clear sequential flow. The system starts with two distinct clar grey PVC pipes coming from the house: one from the bathroom and one from the kitchen. The kitchen pipe leads into a dedicated underground green grease trap. Sequentially, the pipeline from the green grease trap slopes downward and connects into sewer Inspection Chamber Number 1 which diameter is 0,8 , where it meets the bathroom pipe. From this chamber Number 1, a single continuous clear grey PVC pipe runs downward into a yellow polyethylene septic tank. After the septic tank, the pipe connects to a sewer inspection chamber from infiltration dranages distribution that splits the flow into two black perforated drain pipes whose heading opposite directions, inside two infiltration trenches, whose are at the bottom of them, are filled with detailed layers of gravel and coarse sand. Clean visual layout, highly aesthetic, natural dirt trench texture with realistic green grass on top, clear technical visualization.
AI model: Exterior AI
Created: September 15, 2026
Seed: 1
