I need a working plan sketch for the above image, it is for a Cantilever and storage tub timber sorting rack for my workshop. It needs to be the below dimensions. The proposed timber recovery station measures 1,200 mm wide × 1,200 mm high × 413 mm deep, providing a balanced square profile while limiting its projection into the workshop. Two upper storage tiers accommodate longer timber, while three bins below separate shorter offcuts by material type. Each bin measures 380 mm wide × 350 mm deep, with a 250 mm rear height tapering to 130 mm at the front for visibility and access. The bins will be mounted on a French cleat system, allowing them to be removed for cleaning, sorting or relocation when needed. Final dimensions and cleat clearances will be confirmed against the available space and typical offcut sizes.

Prompt: I need a working plan sketch for the above image, it is for a Cantilever and storage tub timber sorting rack for my workshop. It needs to be the below dimensions. The proposed timber recovery station measures 1,200 mm wide × 1,200 mm high × 413 mm deep, providing a balanced square profile while limiting its projection into the workshop. Two upper storage tiers accommodate longer timber, while three bins below separate shorter offcuts by material type. Each bin measures 380 mm wide × 350 mm deep, with a 250 mm rear height tapering to 130 mm at the front for visibility and access. The bins will be mounted on a French cleat system, allowing them to be removed for cleaning, sorting or relocation when needed. Final dimensions and cleat clearances will be confirmed against the available space and typical offcut sizes.
AI model: Exterior AI
Created: October 19, 2026
